Eclipse
Push Button Switch
Stylish & Radiant
Eclipse
Push Button Switch
Stylish & Radiant
FUNCTIONALITY
Sense and Control the Ambient
Eclipse Switch is designed to control the ambient in a stylish way,
thanks to premium materials and finishes.
It is also equipped with multiple sensors to automate the ambient;
thus becomes a switch, a sensor and a design material.
PREMIUM
MATERIALS
ECLIPSE
DESIGN LINE
PUSH-BUTTON
SWITCH
1-2-4
FOLD OPTIONS
PREMIUM MATERIALS
ECLIPSE DESIGN LINE
PUSH-BUTTON SWITCH
1-2-4 FOLD OPTIONS
DESIGN
Customizable
Backlit Icons
CUSTOMIZABLE ICONS
Icon or text can be engraved to each buttons in folds. Thanks to dedicated online planner, customer can select icons from extensive icon library or write text accordingly.
RGB BACKLIGHTS
RGB Backlights of the icons indicate the status of connected load. Color of the backlight can be configured via ETS programming tool.
ADAPTIVE BACKLIGHTS
Light sensor measures ambient light and icon backlights are dimmed according to the light level in the room.
PROXIMITY SENSOR
Proximity sensor senses the approach and backlights of icons are dimmed up to welcome customer in the dark ambients.
DESIGN
Premium Finishes
for Exclusive Living Spaces
Brushed Finish
Pure form of stainless steel, brass and aluminum are brushed with perfect craftsmanship to provide satin effect in each touch to the device.
Stainless Steel
Brass
Aluminum Black
Aluminum Grey
Stainless Steel
Brass
Aluminum Black
Verdant
Silky-Matte Finish
Aluminum is painted with unique colors and coated with special techniques to provide silky feeling in each touch to the product.
Glacier White
Titanium Grey
Obsidien Black
Sand Beige
Verdant
Cocoa Grey
FUNCTIONALITY
More than just a Switch
Eclipse Switch can activate many functions like other smart switches does such as switching and dimming. Besides these, it can do much more with its built-in logic functions and multiple sensors.
BUILT-IN THERMOSTAT
Eclipse Switch can control HVAC systems via built-in thermostat logic, temperature sensor and humidity sensor.
AIR QUALITY SENSOR
Eclipse Switch measures CO2 inside the room with its built-in sensor and determine air-quality of the room. According to the air-quality level of the room, logic functions can be triggered via KNX systems.
DESIGN
Gallery
INFO
Technical Specs
Sensors
Temperature & Humidity
CO2
Proximity & Light
Dimensions
86mm X 86mm X 11mm
Fold Material
Aluminum
Brass
Stainless Steel
depending on the finish selection
Power
29 VDC – 13 Watts
from KNX Bus-line
Connectivity
KNX-TP
Installation
German IEC/EN 60670 Inwall Box
